Inov8 Restaurant HW210 MultiFuel Boiler

HW210-Restaurant-Boiler
Combustion Engineering makes the difference for the successful burning of used fryer oils. INOV8 burners that have been designed for this purpose, combined with an extra hot combustion zone, assures complete combustion of these high flashpoint oils. INOV8 has approved several appliances paired with two burner options (shown at right) that allow the use of WVO oil. Vegetable oils yield about 90% of the BTU value of petroleum oil. When burned properly they are an excellent source of renewable energy that is as GREEN as it gets. Nearly 20 years of experience combined with patented burner technology assures these uncompromised results: • Economic Results—Typical payback periods are within a couple years of purchase. Savings come from utilizing available waste oil as fuel, eliminating disposal costs & storage mess and the long life of the heater. • Environmental Results—All reports show biofuels to significantly reduce carbon emissions. INOV8 burners (burning any oil) yield even lower emissions than clean fuels because of these design features: higher oil temperature, filtering & vapor removal of heated oil, and a patented needle valve to prevent dripping. • Safety Results—INOV8 has never yielded to pressure to use a low cost flame safeguard but has provided customers with the highest protection available, such as: 90 second pre-purge, 10 second trial for ignition, three-second fuel shutoff, seven electronic checks, UV flame sensor, main flame trial-for-ignition. • Convenience —For convenient installations the HW series includes a circulating pump, Low Water Cut-off, Combination Pressure/Temperature Gauge, Relief Valve, Second Safety High Limit with Manual Reset, Honeywell Aquastat, and a Vessel Pressure Rating of 125 PSIG. In most cases the installation is easy and low cost. INOV8 chose a Triad Boiler for its Superior Features, Convenient Installation, Easy Maintenance and Long Life (see cut-away) Triad Boilers have features not available on cast iron or other steel boilers. These come fully wired and ready to install. They will fit through any standard 32” door opening. The boilers do not require assembling on the job site and include most safety components required for a complete installation. The construction allows for easy cleaning of both the water side and the combustion side of the boiler. Cleaning is vital to maintaining high efficiency. The fire tubes are accessed through the top and through the fire door. If repairs are necessary, they can often be done onsite. Boilers can be ordered for domestic water only, hydronic heat only or a combination. The small foot print allows for easy replacement of conventional hot water heaters. Another advantage is that these are qualified as low pressure boilers providing a life expectancy of over 20 years versus a water heater’s average life of 7. *Boiler Model #: HW210 HW610 *Oil Input - at full GPH 1.53 4.23 *Gross Output 186,300 503,100 *Net IBR 162,000 437,400 *Boiler Diameter 22” 30 1/2” *Boiler Height 57 1/2” 66” *Fire Box Depth 16” 25” *Dry Weight (lbs) 600 1,585 *Water Content (gal) 19.3 52.6 *Domestic Water GPM @ 100 F Rise 3.4 10.2 *Space Heating GPM @ 20 F Rise 17.0 51 *Chimney Diameter 6"- 8" *Efficiency 82% 85% *Electrical: 120V, 60Hz, Sgl 20 amp 30 amp *Shipping weight—lbs 750 1,300 *Operating weight—lbs 1,040 1,922 *Chimney specs—Category I 8”-10” *Compressed air requirement 2 cfm @ 35 psig *Manifold Gas Pressure: .71 to 3.0 *Note: ratings assume 140,000 BTUs/gallon. Optional Equipment Available: • Air compressors—either 20 gallon tank compressor • Vegetable Oil Filtration System—304 SS strainer basket and mount • Oil transfer pump • Oil storage tank
Economic Alternative Fuel Options: Gas or Fryer oil fueled water heater: INOV8 Multi‐fueled Water Heaters provide unlimited options for heating water. This fully equipped vertical boiler is an easy replacement for typical hot water heaters for domestic hot water and/or space heating. Used fryer oil and other biofuels can be used as fuel for incomparable fuel options and reliability. If space or budget doesn’t allow for redundant systems, INOV8’s newly introduced gas‐oil burner can use as fuel gas or oil or both at the same time. The control system senses a loss of oil and automatically reverts the fuel to gas for no interruption to your hot water. Savings from energy and disposal costs typically provide a two year payback. INOV8 model HW210 waste fryer oil fueled water heater. This system consists of a vertical steel tube boiler combined with an INOV8 dual-fuel burner that is controlled by a PLC (programmable logic control) to allow the use of fryer oil as the primary fuel, but have an automatic backup system to natural gas. The boiler can be customized to a desired BTU performance, but is factory set at 210,000 BTUs per hour, which consumes about 1.5 gallons per hour of fryer oil. This assumes the oil BTU value is 130,000 BTUs per gallon. The system includes all controls necessary to operate the fuels, to operate and provide custom settings for the water heater functioning. The INOV8 water heater with dual-fuel burning capability is specifically designed to use available waste fryer oil as fuel to generate hot water. If the oil is depleted the system is designed to sense a loss of oil pressure and automatically revert the fuel selection to gas without interruption to the production of hot water. The water heater control will display a notification that the fuel was changed to gas to allow the operator to respond when convenient. This system was designed to accommodate the characteristics of the fryer oil taking into account the high flash point of the oil, the filtering requirements, to provide for an automatic backup, and the ability to customize controls for hot water requirements. This hot water system includes: a boiler and dual-fuel burner rated at 210,000 BTUs, a control system that includes a PLC (programmable logic control) for custom settings and automatic fuel function, a gas valve train, oil control system, a cleanable in-line filter, an installation and operation instruction manual and spare filters and fuses. Optional items are available to complete the system, including a 50 gallon polyethylene oil storage tank with a built-in heating system, an oil level device that displays a remote light indicating empty and full tank levels, a chimney system that includes a provision for preheating fresh air for combustion, and an oil transfer pump capable of handling hot oil directly from the fryer. Benefits of a Boiler Used for a Water Heater: Commercial water heaters have a life expectancy in the seven year range, though industry contacts report failings as early as four years. The failing occurs due to the light-weight materials used in the construction of the water heater. By comparison the Triad Boiler used by INOV8 as the boiler for our water heater, is constructed of steel that is 17% to 33% heavier than industry requirements, and is rolled or expanded into place to prevent thermal stressing common from welded boilers. Each boiler has ASME certification as a pressure-fired vessel. That all means that this INOV8 water heater will last at least 20 years – but likely much longer. When used for domestic hot water, boilers are covered by the same installation codes as a water heater; they generally do not require annual boiler inspections and can be installed by your local plumber. Performance & Savings: For restaurants generating fryer oil and interested in “Green” initiatives for their energy consumption this is a perfect solution. Independent analysis by Brooke Haven National Laboratories found that biofuels generate significantly less greenhouse emissions than standard fuels, including less CO, NOx, SO2 and a little less in CO2. When burning vegetable oil as fuel it yields a carbon neutral effect as the fuel is simply releasing the C02 it absorbed in the growing process. Additional benefits are seen in the reduction of the mess and handling of the waste fryer oil; elimination of disposal costs, and a significant reduction in the consumption of fossil fuels. The resulting “green” that goes into our pockets also feels pretty good. Most users report savings that cover the cost of the equipment within two years. 30 gallons of fryer oil a week generates nearly 600 gallons of hot water each day. The heavy duty construction and sophisticated control package promises many years of satisfaction beyond conventional water heaters. Please contact us for pricing & more detailed specifications.
