Used Nachi 400kg Robot

Nachi-400kg-Robot
35000   USD
SPECIFICATIONS Robot model SC400L Construction Articulated construction Number of axes 6 Drive system AC servo system Max. operating area Arm J1 Swivel +/-2.62rad J2 Upward/downward +1.83 to -0.44rad J3 Forward/backward +2.09 to -0.44rad Wrist J4 Rotation2 +/-5.24rad J5 Bending +/-2.09rad J6 Rotation1 +/-6.28rad Max. speed Arm J1 Swivel 1.40rad/s J2 Upward/downward 1.40rad/s J3 Forward/backward 1.40rad/s Wrist J4 Rotation2 1.57rad/s J5 Bending 1.57rad/s J6 Rotation1 2.53rad/s Payload Wrist 400kg Arm J3 forearm 30kg (*1) Forearm 10kg (*2) wrist torque J4 Rotation2 1960N·m J5 Bending 1960N·m J6 Rotation1 980N·m wrist moment of inertia J4 Rotation2 200kg·m2 J5 Bending 200kg·m2 J6 Rotation1 147kg·m2 Position repeat accuracy +/-0.5mm Installation parameters Ambient temperature 0 to 45°C Ambient 20 to 85%RH (without condensation) Vibration Less than 0.5G Robot type Shelf mount Robot mass 3,800kg Please contact us for further details: info@robotics.ca
NACHI SC400L Robot with AX Controller, Payload capacity 400 kg · Easily handles heavy loads like car bodies. 4.8 meter vertical stroke.
